BC-250 Persistent ACPI

Safe alternative to BIOS flashing: a persistent ACPI fix for the AMD BC-250 that gives the board CPU C-states (idle) and frequency scaling (800 MHz – 3.2 GHz, 8 steps) on Linux — without the P3.00 MeiMeiDXE v3 modded BIOS.

The ACPI tables come from e-tho/bc250-acpi-fix (maintained fork of bc250-collective/bc250-acpi-fix), vendored here from release v1.1.1. Three SSDT overrides are loaded from an early initrd via the kernel's ACPI table upgrade:

Table Fixes
SSDT-CPU Replaces the broken idle-state table (C-states)
SSDT-PST Publishes the 8 frequency states
SSDT-STUBS Defines missing firmware methods as no-ops

Works on stock 6-core and unlocked 8-core boards, on all stock BIOS versions (1.00, 2.00, 3.00 and 5.00 share the same DSDT).

Is this ACPI fix persistent?

Yes, it survives updates:

  • /boot/acpi_override.cpio — extra files in /boot are left alone by rpm-ostree / bootc image updates; only /boot/ostree and /boot/loader are managed.
  • /etc/default/grub — /etc is machine-local state on ostree systems and is 3-way-merged across deployments, so the GRUB_EARLY_INITRD_LINUX_CUSTOM line stays.
  • Kernel updates: Fedora's blscfg GRUB module prepends the early initrd to every BLS boot entry at boot time, including kernels installed later. No re-install, no regeneration needed after a kernel or image update.

Unlike BIOS flashing it is fully reversible (Uninstall in the app, sudo ./bc250-acpi-override.sh --uninstall, or just delete the file and the GRUB line) and carries zero bricking risk.

Install (Bazzite / Universal Blue)

Install the app from the BC250 Bazzite Suite portal, or from a clone or release folder, as your own user (not with sudo):

./install.sh                         # app menu entry and Desktop icon
./install.sh --no-desktop-shortcut   # app menu entry only

Installing the app changes nothing on the board. Open BC-250 Persistent ACPI and click Install, then reboot. The window shows whether the override is installed, the CPU's frequency steps and idle states, and (with Status with sudo) whether the kernel loaded the tables this boot.

From a terminal, without the app:

sudo ./bc250-acpi-override.sh --install
# reboot

The installer checks for a BC-250 GPU, warns on modded BIOSes (duplicate tables fail to load — do not combine this with a modded BIOS that injects its own fixes), verifies CONFIG_ACPI_TABLE_UPGRADE, installs the cpio, adds the GRUB line idempotently and runs ujust regenerate-grub (or grub2-mkconfig on plain Fedora, where the path in GRUB_EARLY_INITRD_LINUX_CUSTOM is relative to /boot/grub2/). In a terminal a warning asks "Continue anyway?"; the app shows the warning in a dialog. --yes answers yes to both warnings.

Manual install

sudo cp tables/acpi_override.cpio /boot/
echo 'GRUB_EARLY_INITRD_LINUX_CUSTOM="../../acpi_override.cpio"' | sudo tee -a /etc/default/grub
ujust regenerate-grub   # then reboot

Verify

The app's status shows the same information. From a terminal:

./bc250-acpi-override.sh --status                    # installed? frequency steps, idle states
sudo dmesg | grep -iE 'ACPI.*(SSDT|Table Upgrade)'   # 3 tables loaded as override
cpupower frequency-info                              # 8 steps, 800 MHz - 3.2 GHz
cpupower idle-info                                   # POLL, C1, C2 (C2 at 0x414)

Or run test 26 of BC-250 Bazzite Test, which reports whether the ACPI tables came from the initrd override or the BIOS.

Uninstall

Click Uninstall in the app and reboot, or from a terminal:

sudo ./bc250-acpi-override.sh --uninstall
# reboot

To remove the app itself: ./install.sh --uninstall (add --purge to also remove its settings). This leaves the override as it is; uninstall the override first if you want the board back on the BIOS tables.

Vendored artifacts

tables/ contains the unmodified assets of e-tho/bc250-acpi-fix v1.1.1 (MIT):

b2f5cd6279ef5992f6482a1702e1dd5c0ebeeaf950fde487d7556ef7a291956b  acpi_override.cpio
9cfc1a254ea8814988d5a700e2dba8ebbe4f290a3895435512ea8afa3ba6a46f  SSDT-CPU.aml
cb3c96c622d2d653777020283c434f92c26bf2c83502a27d9a398f98424a771f  SSDT-PST.aml
c219ce775476725d49739024e149556228436a1c3faf0768a7c3eff9d85f66c2  SSDT-STUBS.aml

To rebuild from source instead, see the upstream Makefile (needs acpica/iasl).

Acknowledgements

  • e-tho — maintained tables and installation method.
  • shinf1x — original tables.
  • rw-r-r-0644 — idle-table diagnosis and ACPI error cleanup.
  • mendesrr — 8-core extension.

License

MIT — see LICENSE. Vendored tables are MIT-licensed by their upstream authors.
