shadPS4 Manager¶

Plays PS4 games on the AMD BC-250 with shadPS4, an open-source PS4 emulator. The app installs the shadPS4 release it was tried with, finds the games in your game folders and adds them to Steam, so a game starts straight away like any other, on the desktop or from Steam's Big Picture Mode. It also unpacks package files (.pkg) into a game folder, with Games Install (Extract PKG).

Whether a game runs, and how well, is up to shadPS4. Its compatibility list shows what others found.

What you need¶

Your games, installed from your own PS4: each game in a folder of its own, with its eboot.bin and its sce_sys folder, or as a package file (.pkg) that Extract PKG unpacks into that layout. The app never downloads games.
System modules for some games: libraries of the PS4's firmware (.sprx files), from your own console. Many games run without them. The app cannot ship them; it shows which ones are there.
Steam, started at least once.
About 35 MB for shadPS4 itself. Its saves, settings and shader cache go in ~/.local/share/shadPS4.
FUSE 2 (libfuse.so.2), which Bazzite has. shadPS4 comes as an AppImage, which mounts itself with it. Without it, it unpacks itself to a temporary folder on every start, which takes longer.

Using it¶

The header shows the shadPS4 version, Your games (the games found), those Available in Steam and the Play time: the time spent in all your games together, as shadPS4 counts it, with each game's time and when it was last played in the tooltip. Refresh reads everything again. Beside the title, next to the app's state, stand shadNet's state (see shadNet) and the controller's: Controller connected, or No controller when none is, looked at again every few seconds. A game started from Steam reads the controller that is connected when it starts, so switch yours on, or press its PS button to wake it, before starting a game. When Steam starts a game without one, the app also says so in a desktop notification. Under the introduction, which links to shadPS4's release notes and to this wiki, a row of six pills does the setting up, each with what it is for on top and what it does under it: shadPS4 Install and shadPS4 Uninstall, Modules Install, Games Install and Games Add folder, and shadNet Account. Four lines below them say where each stands, short, with more in their tooltips, and then come three tabs: Your games, Settings and Log.

shadPS4: the version installed (when this version of the app brings another one, the tooltip and the log say so, and Install puts it in). Install downloads shadPS4 from its GitHub release (about 31 MB) and checks it against the checksum this version of the app was tried with before unpacking it. Uninstall takes it out again; shadPS4's own folder, with your saves, settings and system modules, stays.
Sys modules: Ok in green when every module that shadPS4 cannot do without is in its module folder, Missing sys modules in red when one is not (how many there are, which are missing and the folder's path are in the tooltip). Many games run without them. Install asks for the folder with the modules (.sprx files) you copied from your own PS4's firmware and copies them into shadPS4's module folder.
Game folders: the folders shadPS4 looks for games in, by name (the paths and how many games were found are in the tooltip). Add folder adds one through shadPS4 itself, so its own window lists the games too; clicking a folder's name in the line stops looking in it, after a question (the games stay where they are). A game may sit up to five folders deep. Install unpacks a package file into one of them: see Extract PKG.
shadNet: the name of the account shadPS4 signs in with, Off while none is set up, — while shadPS4 has not run yet (the server is in the tooltip). Account sets it up: see shadNet.

Your games¶

The table lists every game found: its title and Id (CUSA…) from the game's own files, its version and its Folder (the folder's name; the path is in the tooltip). Updates and mods are not listed as games: see Game updates and mods. A PS4 game draws its picture for a wide screen itself, so there is no screen setting per game as in the PS2 and PS3 managers.

Game updates and mods¶

Put a game's update in a folder of its own beside the game, named like the game's folder with -UPDATE added (-patch works too). shadPS4 finds it there and uses it when it starts the game: the update's files take the place of the game's, and the game's own folder stays as it is. Mods go the same way, in a folder ending in -mods.

shadps4_games/
├── CUSA11624/            the game: eboot.bin, sce_sys, ...
├── CUSA11624-UPDATE/     its update: its own eboot.bin, sce_sys and the files it changes
└── CUSA11624-mods/       mods for it

Nothing more is needed: you do not add these folders as game folders, and the table lists the game once. An update found beside its game (the same ID, CUSA…) is left out of the table whatever its folder is called. A game copied from a PS4 that had its update installed already has the update in it: it needs no -UPDATE folder and is listed with the update's version.

Steam¶

Tick the games you want in Steam and press Update Steam. The app adds them to Steam as non-Steam games, with the game's own icon and background as their pictures and its icon (sce_sys/icon0.png) as the logo on the banner, and takes out the games you unticked and games it no longer finds. Steam keeps these files in memory, so it closes for the change and starts again in the background. A game added before the app set the logo gets it the next time you press Update Steam, which is on for it until then.

In Steam each game's name starts with its system, for example [PS4] Lumines, so it stands apart from the same title on Steam or on another system in Steam's menus. A game added under its title alone is renamed the next time you press Update Steam, which is on for it until then. Steam sees the renamed game as a new one: its play time stays, but a controller layout or collection you set for it in Steam has to be set again.

The games are in the library under Non-Steam, on the desktop and in Big Picture Mode alike. They start shadPS4 full screen. Steam's menu and Exit game work as for any game, and so does shadPS4's quit window (see Quit a game).

Steam's overlay works over a game started from Steam, in Big Picture Mode and on the desktop: press Shift+Tab or the PS button for the game's page, its controller layout and its settings, without leaving the game. In Big Picture Mode the PS button opens Steam's menu over the game; pressed again there, it opens the power menu, with Exit game and the way out of Big Picture Mode. On the desktop the overlay needs Enable the Steam Overlay while in-game in Steam's settings (In Game).

On a handheld image of Bazzite, whose Game Mode is a Steam session of its own, change Steam from Desktop Mode: in that session Steam cannot close for the change.

Covers¶

A PS4 game has no cover in the shape Steam's library uses, so the app draws one: the game's icon with its title on a dark background. With a SteamGridDB API key, entered under Steam artwork…, the app takes a cover from SteamGridDB for each game instead; the background and the logo on the game's page stay the game's own. See Covers from SteamGridDB for the key, how a game is looked up and how to use a cover of your own.

Steam in the line under the table is a link: it opens Steam's library (Steam starts when it does not run). shadPS4 settings beside it opens shadPS4's own window (Big Picture) for what the app does not set: the controller's buttons, a game's own settings and shadPS4's game list.

Quit a game¶

shadPS4's quit window asks whether to quit: Cross or Enter quits, Circle or Esc goes back to the game. Open it with:

Share + Options on a DualShock 4 or DualSense (Back + Start on other controllers: View + Menu on an Xbox controller), pressed together;
Ctrl+Shift+End on the keyboard, also with the keypad's End (the 1 key with Num Lock off) on a keyboard without an End key of its own.

The app adds these to shadPS4's input_config/global.ini when it starts, and says so in the log; the rest of the file stays as it is. The controller works on the desktop as well, where the keyboard may stay with Big Picture after Steam started the game.

A game started from Steam reads your controllers itself, a DualShock 4 or DualSense with its touchpad and motion sensors. How it works explains both.

Settings¶

shadPS4's settings that matter for playing, each written into shadPS4's own settings file (config.json) the moment you change it, while shadPS4 does not run (it writes its own settings back when it ends); shadPS4 reads them when a game starts, and a game's own settings in shadPS4 (made in its own window) come before them. They are the settings shadPS4's own window offers for every game; the tooltips say what each does.

Picture: VSync (Mailbox, shadPS4's default, shows the newest frame at each refresh without tearing; On waits for each refresh; Off may tear), AMD's FidelityFX upscaling (FSR) with its sharpening (RCAS), HDR and a frame rate counter.
Sound: the sound output library (SDL or OpenAL) and the volume (up to 500 %). Beside the volume stands Bazzite's volume for shadPS4, which is not shadPS4's: Bazzite's sound settings remember a volume and a mute per application, also once it is closed, so a game plays without a sound while shadPS4 is muted there. The app says so, in red, when shadPS4 is muted or turned down to nothing. Unmute beside it turns a muted shadPS4 on again, and Bazzite keeps it on from then on; a volume turned down is changed in the sound applet (the speaker in the panel, under Applications) while a game plays.
Controller and mouse: the controller's motion sensors, and when the mouse pointer hides over the game.
In a game: the PS4's system language, in which a game that has it shows its text, the trophy message and the game's splash screen.

A value shadPS4 knows and the app does not is shown as it is. Everything else shadPS4 can set stays in its own window (shadPS4 settings).

Log¶

Everything the app said and did, with the time: shadPS4 installed or removed, what the app set up in shadPS4, the system modules copied, the game folders added and taken out, the settings changed, shadNet saved, every change to Steam, and every error. Each game started from Steam is logged by its folder's name when it starts, with whether a controller was connected. The same lines are in ~/.local/share/bc250-shadps4-manager/bc250-shadps4-manager.log, which turns over at 1 MB (the three older files are kept). The log holds what the app did, not your SteamGridDB key, your shadNet password or anything else personal.

shadNet¶

shadNet is shadPS4's online service: online trophies, friends and online play, in the games shadPS4 supports online. shadPS4 signs in by itself when a game starts, once it knows your account. shadNet Account opens a window for it:

Server: the shadNet server, srv.shadps4.net:31313 (shadPS4's own) unless you use another one.
shadPS4 user: which of shadPS4's users signs in. Games play as player 1, the first user.
shadNet name and Password: your account. The name has 3 to 16 letters, digits, - or _, and is case-sensitive when you sign in.
Email: needed to create an account.
Registration key: only for a server that asks for one to create an account; its owner gives it to you.

Create account makes a new account on the server with that name, password and email. Try sign-in signs in once and out again, to check the name and password. Save keeps it all in shadPS4's own files, with Sign in to shadNet when a game starts ticked to use it, or unticked to stop. Close shadPS4 before you save: it writes its own settings back when it ends.

The header shows the state of shadNet beside the app's own:

shadNet Online: while a game runs, shadPS4 is signed in. Without a game, the server answers, so shadPS4 can sign in when one starts. The app asks the server without signing in.
shadNet Offline: the server does not answer, or shadPS4's sign-in was refused or dropped. Hold the pointer over it to see why.
shadNet Off: no account is set up, or Sign in to shadNet when a game starts is off.

While shadPS4 runs, the app reads shadPS4's log every few seconds to see whether it signed in.

shadPS4 keeps the password as it is in its users.json, and shadNet sends it over the network unencrypted. Use a password you use nowhere else.

Extract PKG¶

Games Install (or a .pkg dropped on the window) opens Extract PKG, a window that unpacks package files (.pkg: games, patches and add-on content) into the folder layout shadPS4 loads: a TITLE_ID folder (for example CUSA41215) with sce_sys/ and the game's files. Extracted into one of the game folders, a game shows up in the list when the window closes, ready for Steam. It needs no shadPS4 installed.

It can only open a package that shadPS4 can use: a fake-signed (re-encrypted) PKG. Retail packages that still carry their original encryption cannot be opened; the window says Failed to find PFSC header then. A game unpacks to roughly its package size, so the output folder needs that much room.

Drop a .pkg on the window or Browse to it: the icon and the SFO preview fill in at once, before anything is extracted.

SFO Preview: five keys from param.sfo: CATEGORY (gd game, gp patch, ac add-on content), CONTENT_ID, TITLE, TITLE_ID and VERSION. When the package has no readable param.sfo, CONTENT_ID and TITLE_ID come from the package header. Right-click the preview to copy a line, only its value, or everything.
icon preview (click): the package's icon0.png, or the app's logo when there is none. Click it to see the package's pic0.png (or pic1.png) full screen; a click, Esc or the B button closes it. Right-click the icon, or the full screen picture, for save as wallpaper: it saves the picture as a PNG, named after the content id, to your Pictures folder or wherever you choose. The icon's menu also has show full screen.
Rename to CONTENT_ID: renames the package file to its content id, UP9000-CUSA00038_00-ASTRONAUT0000002.pkg. A game or patch gets its APP_VER appended without the dot (...-0100.pkg), add-on content (CATEGORY ac) keeps the content id alone. The window says so when the file already has that name or another file has it.
Output: the folder the TITLE_ID folder goes into: the one you used last, or else the first of shadPS4's game folders. The line below it says whether it is a game folder; a game extracted elsewhere shows up only once you add that folder (Games Add folder). The window refuses to extract into a TITLE_ID folder that already has something in it, and lists what it found: each extraction or preview needs a fresh folder, so nothing is mixed with an earlier run.
Updates: an update (CATEGORY gp) for a game that is in the output folder goes into a folder beside it, TITLE_ID-UPDATE (for example CUSA41215-UPDATE). shadPS4 lays it over the game when the game starts, so the game's own folder stays as it is, and deleting the -UPDATE folder takes the update out. When the folder holds an update already, the window asks whether to replace it: the new one is extracted beside it first and takes its place only when every file was written, else the old one stays. An update package extracted without its game in the output folder goes into TITLE_ID, as a game does: a package with the game and its update in one says gp too.
Extract PKG: writes sce_sys/ (the package's metadata files: param.sfo, icons, pictures, trophies, the decrypted license.dat, nptitle.dat and npbind.dat), then every file of the package, with the progress bar counting files. When it is done, the output folder opens in your file manager. The log at the bottom shows each step and each file; the same lines go to the log file (see What goes where).
Preview Only: writes only sce_sys/ and filelist.txt, the list of every file the package holds with its inode and the path it would get. Use it to see what is inside, or to check a package, without the full extraction.
Salvage Mode (skip bad metadata): a package with damaged metadata normally stops the extraction at the first bad entry, so you see that something is wrong. With Salvage Mode on, bad entries are skipped and the rest is extracted; the log ends with a recovery summary, and the folder gets salvage_report.txt (the skipped entries) and extraction_errors.txt (every error). Files that failed are missing or incomplete; shadPS4 may still run the game when they are not needed.
Compare Extractions opens a menu with two tools. Compare two extraction folders… compares, for example, this window's output with another tool's: which files only one of them has, which differ in size and, when you answer Yes to the hash question, which differ in content (SHA-256, slower). The summary goes to the log and a JSON report (compare_report_<date>.json) into the first folder. Both folders' filelist.txt, when present, are compared too. Delta between two compare reports… takes a before and an after report, for example from before and after a change in the extractor, and tells per count what went up or down and which files were fixed or are new; the text goes to the log and to <after report>_delta.txt next to the after report.

While an extraction runs, the buttons are grayed out and the window stays open until it has finished. When the window opens and finds that an earlier one did not end cleanly (the app stopped while it was open), it says so, with the last file it was extracting; a partial TITLE_ID folder from then is refused by the empty-folder check: delete it.

<game folder>/CUSA00038/
├── sce_sys/            param.sfo, icon0.png, pic0.png, pic1.png, trophy/, license.dat, ...
├── eboot.bin           the game's files, in the package's own folder tree
├── ...
└── filelist.txt        every entry of the package: index, inode, type, name and path

Patches and add-on content extract the same way into their own folders. For an update, rename its folder after the game's with -UPDATE added: see Game updates and mods.

A small add-on package that only carries metadata (an unlock key) has no files besides sce_sys/; the window says "no extractable outer PFS entries detected" and extracts what there is. Some such packages name no files at all; their one data block is then written as inode_1.bin.

When a package does not extract:

"is not a valid PKG file": the file does not start with the PKG magic; it is not a package, or it is truncated at the start.
"Failed to find PFSC header": the package's file system could not be decrypted: the package keeps its retail encryption, or it is damaged. Only fake-signed packages can be extracted.
"Guardrail: target output folder is not empty": choose or make an empty folder; the TITLE_ID folder under it must not exist yet or must be empty. An update is the exception: see Updates above.
"PKG file size is different": the file is shorter than its header says: an incomplete download or copy.
Preflight failed for file N: the package's metadata for that file is inconsistent. Switch on Salvage Mode to get the other files.

A package is a table of metadata entries followed by an encrypted PFS file system image. The window reads the table, derives the keys the way the console does for fake-signed packages (the "derived key 3" RSA block in entry_keys, the image key in image_key, from them the EKPFS key, and with the seed in the image header the AES-XTS data and tweak keys), decrypts the PFS, finds the compressed PFSC container in it, reads its inodes and directory entries, and inflates each file block by block. It is a port of the C++ tool pkgxtractor (src/core/file_format/pkg.cpp, crypto.cpp, psf.cpp, themselves from shadPS4), so the two give the same files, and the same messages when a package is bad.

From a terminal¶

bc250-shadps4-run starts the installed shadPS4 with the options you give it. The Steam shortcuts use it, so they keep working when a newer version of the app brings a newer shadPS4.

bc250-shadps4-run -f true -g "/path/to/game/eboot.bin"   # a game, full screen
bc250-shadps4-run -g "/path/to/game/eboot.bin"           # a game, as shadPS4's settings say
bc250-shadps4-run -b                                     # shadPS4's own window

The app itself takes a package: bc250-shadps4-manager file.pkg opens it in Extract PKG, as opening a package with the app from the file manager does. When the app is open already, the package goes to the open window. bc250-shadps4-pkg-cli extracts without a window:

bc250-shadps4-pkg-cli <file.pkg> [output folder] [--salvage] [--preview-only] [--no-subfolder]

It prints the package's content id, title and SFO keys, extracts into <output>/<TITLE_ID>/ (the output folder defaults to the package's folder; --no-subfolder extracts straight into it), and writes filelist.txt. --preview-only stops after sce_sys/ and the list; --salvage skips bad entries. It exits with 0 when every file was written, 2 when some failed, 1 when the package could not be opened. The two comparison tools run from the app folder (~/.local/share/bc250-shadps4-manager/app, with the app's venv's python):

python -m shadps4_manager.pkgxtractor.compare <folder A> <folder B> [--hash] [--json-out report.json]
python -m shadps4_manager.pkgxtractor.compare_delta <before.json> <after.json> [--out delta.txt]

New shadPS4 releases¶

Each version of the app installs one shadPS4 release, the one it was tried with. When the window opens, the app asks GitHub for shadPS4's newest release (its stable releases, not the daily development builds). When that one is newer, the shadPS4 line's tooltip and the log say so, with a link to what is new; the app does not install it. A newer shadPS4 comes with a newer version of the app, once it has been tried, from the portal: after updating the app, the tooltip says so, and Install brings it.

How it works¶

The Steam shortcuts start bc250-shadps4-run, which starts shadPS4. Two things change when Steam is the one that starts it. Started from a terminal, outside Steam, shadPS4 runs as it is.

Controllers¶

When Steam starts a game, it tells the game's controller library (SDL) to ignore the controllers Steam handles itself, and gives the game Steam's virtual controller in their place (Steam Input). shadPS4 then sees only that virtual controller:

it has no motion sensors and no touchpad, so a game that uses them cannot;
on the desktop it follows the layout Steam has active. While Steam does not know that the game has the focus, that is Steam's desktop layout (mouse and keys), and the game gets no controller input at all.

So the run wrapper undoes it: while a real controller is connected, shadPS4 reads that controller itself and leaves Steam's virtual one (USB ID 28DE:11FF) out. The PS button stays Steam's. Without a real controller, as on a Steam Deck whose own controls exist only as Steam's virtual controller, the wrapper leaves Steam's choice as it is.

Steam's overlay on the desktop¶

The KDE desktop of Bazzite is a Wayland session. shadPS4 opens its window through Wayland when it can, but Steam on the desktop only sees windows that go through X11 (XWayland, the X11 server within the Wayland session). A game window Steam cannot see has no overlay: Shift+Tab and the PS button do nothing, and there is no way to the game's page, controller layout or settings while it runs. Steam also cannot tell that the game has the focus, which is why its desktop layout stays active (see above).

So when Steam starts a game on the Wayland desktop, the run wrapper has shadPS4 open its window through XWayland (SDL_VIDEO_DRIVER=x11), and Steam's overlay works as in any other game. A handheld's Game Mode runs every game through X11 already.

What goes where¶

What	Where
The app	`~/.local/share/bc250-shadps4-manager/app`
Its Python, with PyQt6 and cryptography	`~/.local/share/bc250-shadps4-manager/venv`
shadPS4	`~/.local/share/bc250-shadps4-manager/emulator`
Extract PKG's log, and its crash marker and progress while it is open	`~/.local/share/bc250-shadps4-manager/pkgxtractor.log`, `.state`, `.progress`
shadPS4's saves, settings, system modules	`~/.local/share/shadPS4` (shadPS4's own folder)
shadPS4's settings (the Settings tab)	`~/.local/share/shadPS4/config.json`, shadPS4's own
shadPS4's play time per game	`~/.local/share/shadPS4/play_time.txt`, shadPS4's own
The app's log	`~/.local/share/bc250-shadps4-manager/bc250-shadps4-manager.log`
Your shadNet account	`~/.local/share/shadPS4/users.json`, the server in its `config.json`
The quit hotkeys	`~/.local/share/shadPS4/input_config/global.ini`
The app's settings, with Extract PKG's last used folders	`~/.config/bc250-shadps4-manager`
The Steam shortcuts	Steam's `shortcuts.vdf` and `grid` folder, per Steam user
The covers found on SteamGridDB	`~/.local/share/bc250-shadps4-manager/covers`
Launchers	`~/.local/bin/bc250-shadps4-manager`, `~/.local/bin/bc250-shadps4-run`, `~/.local/bin/bc250-shadps4-pkg-cli`

Install and remove¶

Install the app from the portal, where it is under Gaming. Removing it takes out the app and the shadPS4 it installed; shadPS4's own folder (your saves) and your games stay. The games in Steam then no longer start: take them out first by unticking them and pressing Update Steam.

Installing the app also removes the standalone Bazzite pkgxtractor, whose package extraction is in this app now (Extract PKG). Its settings stay: Extract PKG starts in the folders you last used there.

./install.sh                         # install or update
./install.sh --no-desktop-shortcut   # app menu entry only, no icon on the Desktop
./install.sh --uninstall             # remove the app and the shadPS4 it installed; keeps its settings and log
./install.sh --uninstall --purge     # also remove its settings, covers and logs

Disclaimer¶

shadPS4 Manager is an independent project, not affiliated with or endorsed by the makers of PlayStation. PlayStation and PS4 are trademarks of their owner.

License¶

GPL-3.0-or-later. shadPS4 is a separate program under its own license (GPL-2.0), downloaded from its own release. Extract PKG's PKG/PFS/PSF code is a port of shadPS4's (GPL-2.0-or-later).
