BC-250 Upscaler Manager¶

PyQt6 front-end that deploys HelixSR – the FSR 3.1 drop-in upscaler with DLSS-style neural networks – into games on an AMD BC-250 board running Bazzite (Fedora Atomic / rpm-ostree), and keeps track of where it was put.

HelixSR is not an injector: it is a replacement for the amd_fidelityfx_upscaler_dx12.dll / amd_fidelityfx_dx12.dll a game ships with. Deploying it means renaming the game's DLL to *.original.dll and dropping HelixSR's DLL, its two network files and an optional helixsr.ini in the same folder. This app does exactly that, reversibly, and nothing else on the system is touched. No launch options, no WINEDLLOVERRIDES, no Proton tweaks are needed. Only OptiScaler, for games without FSR 3.1, needs a launch option; the app sets that one too (see below).

What it manages¶

Setup in one click – Download and build fetches the latest HelixSR release from GitHub (checked against the SHA-256 GitHub publishes for it), reads the exact URLs and SHA-256 sums its setup scripts pin, downloads what the PC still needs in parallel and verified (NVIDIA's DLSS 310.7.0 DLL, 59 MB; Microsoft's DirectX Shader Compiler, 25 MB; on Bazzite a portable Python, 67 MB), runs helixsr-setup.sh --yes with live output and imports the result as the payload. The DLSS DLL is deleted afterwards. A DLSS 310.7.0 DLL from a game you own can be used instead (Find in Steam compares checksums), which skips NVIDIA's download. The build itself is HelixSR's own script, unchanged: about 5–6 minutes on a BC-250, because it compiles the network's shaders for both wave sizes through Proton. The Setup page shows the elapsed time. From HelixSR 1.7.0 on, the script ends with its own game installer, which asks about each Steam game; the app gives it no input, so it stops there and only the network files are built. From HelixSR 1.8.0 on, the network is built into HelixSR's DLL instead of two separate files. From HelixSR 1.9.0 on, the script can also build frame generation for HelixSR Scaler (about 400 MB from NVIDIA); the app does not deploy that, so it skips this step (--no-fg). HelixSR 2.x keeps its DLL in the release's HelixSR-fsrfg folder, and its helixsr-setup.sh --yes would install HelixSR Scaler into every game it finds. For 2.x the app therefore runs what that script runs before its game installer: HelixSR's own builder (setup/helixsr_setup.py, unchanged) on HelixSR-fsrfg, with the same Python, shader compiler and Proton, and without frame generation (--no-fg). It then checks that the DLL carries the network. Your games are only changed from the Deploy and Games pages. When a later major version is out that the app does not support yet, the Setup page says so and the app keeps getting the newest release it supports.
Version choice – Version on the Setup page picks the latest HelixSR release (the default) or HelixSR 1.8.1, the version HelixSR's developer recommends when the latest one does not work for you (please then open an issue at HelixSR with the game's helixsr.log). Switching builds the network files for that version and replaces the payload; deploy again per game afterwards.
Update checks – at start (can be turned off) or on demand: the payload against the latest HelixSR release on GitHub. The app itself is updated through the BC250 Bazzite Suite portal. A newer HelixSR is flagged on the Overview; building again updates the payload and deployed games show Older build (Newer build after switching back to 1.8.1). After a build the app offers to update them; Update older games on the Overview does the same, for older builds and for games whose own DLL is back, keeping their helixsr.ini. Download and build needs about 1.5 GB free.
Games – every Steam game, each looked through in the background for an AMD FSR 3.1 DLL: the games that have one first, with HelixSR's state in each; the others grayed out (Open on Deploy page still takes them to OptiScaler). Run with HelixSR (or a double-click) puts HelixSR in when it is missing, older, or replaced by the game's own DLL after an update, then starts the game through Steam (steam://rungameid/<AppID>). It asks before the first install into a game and does nothing while the game runs.
Payload – one imported HelixSR release, kept under ~/.local/share/bc250-upscaler/payload. Filled by the Setup page, or by hand: run the release's helixsr-setup.sh yourself and import the folder or the zip. It builds helixsr_weights.bin and helixsr_kernels.pak from NVIDIA's DLSS DLL – those files are NVIDIA's property, so this app never ships them. Only the known HelixSR files are copied; the payload survives updates and ./install.sh --uninstall.
Deployments – every place HelixSR was put, with a live status (in place, older or newer build, network files missing, original restored when a game update or Steam put the game's own DLL back, folder gone), in ~/.config/bc250-upscaler/deployments.json.
Two deploy modes
Replace the game's DLL – for games with native FSR 3.1: pick the game folder (Steam libraries are scanned, including libraryfolders.vdf and the Flatpak Steam), the app finds every upscaler DLL (Unreal games bury it under Engine/Plugins/.../ThirdParty/Win64), backs it up and deploys. Remove restores the original. Re-deploying a newer build never overwrites the real original.
Stand-alone folder for OptiScaler – for games without FSR 3.1: writes a folder with the DLL under both FidelityFX names, the network files and the ini. With a payload from HelixSR 1.7.0 to 1.8.1, which ship the official OptiScaler (1.9.0 and newer do not; the fallback on the Setup page brings it, and the payload keeps it when you switch back to the latest), it also installs OptiScaler next to the game's .exe (Scan finds that folder): as dxgi.dll, or under the name of an OptiScaler the game already has, with fakenvapi, and its OptiScaler.ini pointed at the HelixSR folder. Select DLSS in the game. What it replaces is kept in the HelixSR folder's backup; Remove puts it back. Under Proton OptiScaler only loads with WINEDLLOVERRIDES="dxgi=n,b" in the game's Steam launch options, so for a Steam game the app adds that too: to the launch options already there (WINEDLLOVERRIDES="dxgi=n,b" %command% when there are none), for every Steam user. Steam writes its settings again when it closes, so it has to be closed for this: the app asks, closes Steam, sets them and starts Steam again. In Game Mode Steam stays open; the line is then copied to the clipboard to paste into the game's Properties in Steam. Remove puts the launch options back as they were, unless you changed them since. Untick it to install OptiScaler yourself: the page then gives you the OptiScaler.ini lines (Dx12Upscaler=fsr31, FfxDx12Path, FfxDx12SRPath as Z:\ paths) to paste. Optionally it adds a second upscaler, for example AMD's amd_fidelityfx_upscaler_dx12.dll with FSR 4: it goes into the folder as amd_fidelityfx_upscaler_dx12.amd.dll with UpscalerDll pointing at it, and OptiScaler's FFX Upscaler menu lists its upscalers after HelixSR.
helixsr.ini – a form over every key HelixSR reads ([Sharpening], [ModelE], [Log], [Forwarding]) with validation and a live preview that keeps the upstream comments. Save it as the default for new deployments or push it to an existing one. The page grays out what the payload's HelixSR version does not read: HelixSR 1.7 ignores [Sharpening] and [ModelE] Network; 1.8 reads sharpening again through Sharpener (off, nvidia or rcas), Sharpness and UseGameSlider instead of Mode.

Privilege model¶

Everything runs as your normal desktop user: game folders under Steam are yours, the payload and the deployment list live in your XDG directories. No pkexec, no root, no rpm-ostree layering. With OptiScaler the app also changes the game's launch options in your Steam settings (userdata/<user>/config/localconfig.vdf), and only that line.

Requirements¶

Python 3.11+
PyQt6>=6.11,<7

The PyQt6 wheels bundle Qt. HelixSR itself needs a game with an FSR 3.1 DX12 upscaler (or OptiScaler) and the network files built by its helixsr-setup.sh; see the HelixSR README for the game side.

Install on Bazzite¶

Install it from the BC250 Bazzite Suite portal, where it is under Gaming. Or download upscaler-v<version>.tar.gz from the suite's releases, unpack it and run the installer:

tar -xzf upscaler-v*.tar.gz
cd upscaler-v*/
./install.sh

It installs the app for your user only: a private venv with PyQt6 and the app under ~/.local/share/bc250-upscaler, the launcher ~/.local/bin/bc250-upscaler, a desktop entry, the icon and a Desktop icon (./install.sh --no-desktop-shortcut leaves the Desktop icon out). BC-250 Upscaler Manager then appears in the application menu (and in Steam's Game Mode via Add a Non-Steam Game if you want it there). Run ./install.sh again from a newer release to update, ./install.sh --uninstall to remove it; the imported payload and the deployed games are left alone. ./install.sh --uninstall --purge also removes the payload and the settings. The list of deployed games stays, so a reinstalled app can still restore them. An installed copy under the app's former name, HelixSR Manager, is taken over: its payload, settings and list of deployed games move to the new folders, its launcher and menu entry go.

Run from the repository¶

git clone https://github.com/RobertoTorino/nexus.git
cd bc250-bazzite-suite/apps/upscaler
python3 -m venv python && python/bin/pip install -r requirements.txt
PYTHONPATH=../../core python/bin/python -m upscaler

--payload DIR, --deployments FILE and --work DIR point the app at another payload folder, deployment list and download folder, for development on a machine without Steam. --no-update-check skips the release lookup at start. --version prints the version.

Pages¶

Overview – payload status (version from the release's README, DLL, weights, kernels, ini) with Import folder / Import zip / Open payload folder, and the deployment table with Open folder, Remove (restores the original or deletes the stand-alone folder), Forget and Update older games.
Setup – release status for HelixSR with Check now; the version to get (latest or 1.8.1); Download and build with progress, the script's output, Cancel, Import built release and Open work folder; optional local nvngx_dlss.dll.
Games – every Steam game with its FSR 3.1 DLL and HelixSR state; Run with HelixSR, Open on Deploy page, Rescan.
Deploy – choose a Steam game or browse to any folder, scan for upscaler DLLs, pick the mode, decide whether to write the current helixsr.ini, deploy or remove. In folder mode the OptiScaler snippet is shown with a Copy button.
helixsr.ini – the settings form, validation, preview, Save as default and Apply to deployment.
Help – the workflow, where the files live, and links to HelixSR and OptiScaler.

The header shows the payload version, network-file status, deployments (ok / total) and the number of Steam games found; it refreshes every 5 seconds.

Development¶

upscaler/
  __init__.py       app name, version, XDG paths
  __main__.py       entry point (python -m upscaler)
  backend.py        pure file logic: payload import, DLL discovery, deploy/remove (both modes),
                    helixsr.ini parse/render/validate, deployment store, Steam library discovery
  acquire.py        GitHub release lookup, pinned-source parsing, verified parallel downloads,
                    the build (QThread: helixsr-setup.sh for 1.x, HelixSR's builder for 2.x) and the
                    update checker
  setup_page.py     Setup page
  main_window.py    header, navigation, polling, confirmations, wiring of page signals to the backend
  pages.py          Overview, Deploy and helixsr.ini pages
  help.py           Help page
  widgets.py        status pills, metric boxes, rounded tooltip (shared with bc250-governor-manager)
bc250_core/         the suite's shared code (its steam.py closes and starts Steam), bundled by install.sh and
                    the release
  fonts/            Inter (SIL OFL), used for the header on Linux
install.sh          per-user installer (venv, launcher, desktop entry, icon); --uninstall removes it, keeps the payload
bc250-upscaler.desktop  desktop entry template, Exec is filled in by install.sh
tests/              pytest suite (offscreen Qt, temporary payload and game folders, no real HelixSR needed)
test.sh             runs it with the project venv

Tests: ./test.sh in the suite's root runs every test suite, this one included (extra arguments go to pytest, e.g. ./test.sh -k ini). For this app alone: pip install -r requirements-dev.txt then QT_QPA_PLATFORM=offscreen python -m pytest -q tests. They cover the helixsr.ini round-trip against the upstream file, payload import from folders and zips, DLL discovery, deploy/remove in both modes (including re-deploy over an older build and refusing foreign DLLs), the deployment store, Steam library parsing, the release lookup and the whole Setup run (downloads over file:// URLs against a fake helixsr-setup.sh and a fake 2.x builder, checksum and script failures, a local DLSS DLL), the main window driven through its page signals and the translations (compiler round-trip through QTranslator, completeness of every shipped language). The suite's CI (.github/workflows/ci.yml) runs them on every push and pull request. Releases are tagged upscaler-v<x.y.z> in the suite repository; .github/workflows/release.yml then builds the tarball and publishes it on GitHub.

The backend has no Qt dependency so it can be exercised from the command line or reused.

License¶

GPL-3.0-or-later, see LICENSE. The bundled Inter font is under the SIL Open Font License (upscaler/fonts/Inter-LICENSE.txt). HelixSR is a separate project under its own license; its network files are derived from NVIDIA's DLSS and are never distributed by this app.
