Bazzite NetcatGUI¶

NetcatGUI is the network "swiss army knife" netcat (nc) with a window instead of a terminal, on a BC-250 running Bazzite or any other Linux desktop. Every tab is one session: a Connect tab talks to a host and port, a Listen tab waits on a port for someone to connect. What you type is sent as bytes, what comes back is shown in the log. TCP, UDP or TLS, per tab.

Use it to poke at a service (type an HTTP request by hand, talk to a game server's text port), to see what a device on the network sends, or to pass lines between two machines. The app does not change how the board runs: nothing is installed system-wide and nothing is layered with rpm-ostree.

What it needs¶

Python 3.10 or newer: Bazzite ships python3. The installer makes the app's own virtual environment with PyQt6 in it (the wheel bundles Qt), so nothing else is needed.
A port the firewall lets through, when another machine is to reach a Listen tab. On Bazzite: sudo firewall-cmd --add-port=4444/tcp opens one until the next reboot.

Install¶

In the portal, open the Development tab and click the Install button beside its icon. Or by hand: from the suite's Releases page, download the ncgui-v<version>.tar.gz release and extract it. Run install.sh as your own user, without sudo:

./install.sh

It installs:

~/.local/share/bazzite-netcatgui/app: the app, and venv next to it with PyQt6.
~/.local/bin/bazzite-netcatgui: starts the window.
An app menu entry ("Bazzite NetcatGUI", under Network) and an icon on the Desktop. ./install.sh --no-desktop-shortcut leaves the Desktop icon out.

Install it again to update. Uninstall it in the portal, or with ./install.sh --uninstall: that removes the app, the venv, the launcher and the menu entry, and keeps your settings; ./install.sh --uninstall --purge removes those too.

Steam Game Mode: add ~/.local/bin/bazzite-netcatgui as a non-Steam game (Steam → Games → Add a Non-Steam Game → Browse) to start it from the Deck UI. The window is resizable and works with touch.

Using it¶

The first line shows the app's logo, its name and version, and the four buttons: New Connect Tab, New Listen Tab, Save Log and Clear Log. The window opens with one empty Connect tab. Every tab has the same three parts: the header with the address, the port, TCP, UDP or TLS and the start button; the log in the middle; the message box with Send at the bottom. The status bar says what the current tab is doing, and the encoding and line ending it uses.

A Connect tab¶

Type the hostname (a name or an IP address) and the port, pick TCP, UDP or TLS, and press Connect (or Ctrl+O). The tab is named after the host and port once connected. Disconnect closes the connection; when the other side closes it, the status bar says "Disconnected by peer". A connection that is refused, or a name that cannot be looked up, shows a message. With UDP there is no connection to make: the tab is "Connected (UDP)" at once, and each message goes out as one datagram; a "connection refused" after a send means nothing listens on that port. TLS is TCP with encryption, for an HTTPS, IMAPS or SMTPS port: the certificate is checked, and when it cannot be verified (self-signed, expired, another name) the app shows why and asks whether to connect anyway.

Reconnect Automatically (Session menu) makes a Connect tab connect again three seconds after the connection drops or fails, again and again, until you press Disconnect. Use it for a server that restarts, or to wait for one to come up: the status bar counts down and no message boxes interrupt. The setting is remembered for new tabs.

A Listen tab¶

Pick the interface (0.0.0.0 is every interface, the default; 127.0.0.1 only this machine), type the port and press Listen. The tab is named after the address and port. With TCP, one client at a time is taken: the status bar shows its address, Send goes to it, and the button turns into Disconnect, which drops the client and keeps listening for the next; a second client that connects while one is there is turned away. Stop (the same button with no client) stops listening. Ctrl+D does the same, one step at a time. With UDP the tab shows every datagram that arrives; Send answers whoever sent the last one, so a message must arrive before you can send. Ports below 1024 need root, which the app does not have: use a port above it. A Listen tab has no TLS: that would need a certificate of its own.

Messages¶

Type in the message box and press Enter (or the Send button, or Ctrl+M from anywhere): the text is sent and the box empties. Shift+Enter makes a new line inside the message. An empty message is not sent. Up and Down in the box walk through the messages you sent before in this tab, like a shell's history (on a message of several lines they move the cursor first; the history takes over on the first and the last line); what you were typing comes back when you walk down past the last one. The Session menu sets, for the current tab and as the default for new tabs:

End Messages with Newline: append a line ending to every message, as a terminal would when you press Enter. Most text protocols (HTTP, SMTP, IRC, telnet-like consoles) want it. Line Ending chooses LF or CRLF; it also applies to the line breaks inside a message of several lines.
Encoding: how the text is turned into bytes, and received bytes into text: UTF-8 (the default), Latin-1 (one byte per character, so it also shows binary-ish data without losing bytes), or the system's locale. A character the encoding does not have is sent as ?; a byte that is not valid text is shown as �.
Echo Sent Messages in the Log: show what you send in the log, between what is received. Off by default, as in the C++ tool.

Received data is shown as it arrives. The log shows CRLF and CR as a line break; Save Log (Ctrl+S) writes the current tab's log to a text file with a short header, Clear Log (Ctrl+K) empties it. The Edit menu's Copy, Paste and Select All act on the log or, when it has the focus, on the message box.

Insert Protocol Template (Edit menu) puts the opening lines of a conversation in the message box: an HTTP GET / or HEAD / with the tab's hostname filled in, SMTP EHLO, POP3 CAPA, IMAP CAPABILITY, FTP USER anonymous, IRC NICK and USER, Redis PING, memcached stats. The tab is switched to "End Messages with Newline" and CRLF, which they all expect; press Enter to send. Highlight Protocol Lines (Session menu, on by default) colors the lines text protocols produce: requests and commands green, status and reply lines orange, error replies (HTTP 4xx and 5xx, SMTP and FTP 4xx and 5xx, -ERR, ERROR) red, header names blue. Plain data stays as it is.

Bytes, not text¶

Hex View (Session menu, Ctrl+H) shows the log as a hexdump instead of text: each chunk as it arrived, with a << line saying how many bytes, then the offset, the bytes in hex and the printable characters. With Echo on, sent chunks appear with >>. Switching back and forth shows everything received so far the other way; Save Log writes what is shown. Hex Input (Ctrl+Shift+H) makes the message box take bytes as hex digits instead of text: 48 65 6c 6c 6f 0a, with or without spaces, colons, 0x or \x. A message that is not valid hex is refused and stays in the box for correction. Both are per tab and off when a tab opens.

Pipes: to a file, from a file, to another tab¶

Save Received Data to File… (File menu) appends every byte the tab receives from then on to a file you choose, as it is, without the text conversion of the log: what nc > file does. The status bar shows the file name; untick the menu entry to stop. The file keeps what it had; a second run appends.
Send File… (File menu, Ctrl+Shift+F) sends a file's bytes through the connection, as they are: what nc < file does. The status bar reports the byte count. The file is not shown in the log, even with Echo on.
Pipe Received Data To (Session menu) sends everything this tab receives from then on out through another tab's connection, as it is: what nc A | nc B does, between two tabs. Pick the other tab in the submenu, or None to stop; the status bar shows the pipe. The receiving tab keeps showing the data in its own log. For both directions, set the pipe on both tabs: data that arrives on tab B is piped to tab A and the other way round. When the other tab has no connection at that moment, the data is shown but not passed on. Closing a tab removes the pipes that point to it.

Recording and replay¶

Every message a tab sends is recorded with the time it went out. Save Session Recording… (File menu) writes these to a .ncrec.json file: the bytes as hex and the pause before each message. Replay Recording… sends such a file through the current tab's connection with the original pauses; the status bar counts the messages, and Disconnect stops a replay. Use it to repeat a login sequence, a handshake or a test script against another host. Files sent with Send File are part of the recording.

Tabs¶

Right-click a tab handle for New Connect Tab, New Listen Tab, Rename Tab…, Tab Color, Close Tab, Close Other Tabs and Close All Tabs; the empty part of the tab bar offers the two New entries. The same lives in the Tabs menu. Rename Tab… (F2) gives a tab a title of your own that stays while the session connects and disconnects; an empty title brings the session's own name back. Tab Color colors the title, to group tabs by eye; None removes it. Titles and colors are not saved between runs.

Keyboard shortcuts¶

Keys	What
Ctrl+T	new Connect tab
Ctrl+L	new Listen tab
F2	rename the tab
Ctrl+W, Ctrl+Shift+W	close the tab, close all tabs
Ctrl+Tab, Ctrl+Shift+Tab	next tab, previous tab
Ctrl+O	connect, or listen, on the current tab
Ctrl+D	disconnect; on a Listen tab drop the client, then stop listening
Enter, Shift+Enter	send the message, new line in the message
Up, Down	earlier, later message in the message box
Ctrl+M	send the message from anywhere in the window
Ctrl+Shift+F	send a file
Ctrl+H, Ctrl+Shift+H	hex view, hex input
Ctrl+S, Ctrl+K	save the log, clear the log
Ctrl+A, Ctrl+C, Ctrl+V	select all, copy, paste
Ctrl+Q	quit

Help → Keyboard Shortcuts shows the same list in the app.

Examples¶

Fetch a web page by hand¶

See exactly what a web server answers, headers and all.

Press Ctrl+T for a Connect tab. Hostname example.org, port 443, protocol TLS (for a plain HTTP site: port 80, TCP). Press Connect; the status bar says "Connected (TLS)".
Edit → Insert Protocol Template → HTTP GET /. The message box now holds the request with Host: example.org; the tab is set to end messages with CRLF.
Press Enter. The log shows HTTP/1.1 200 OK, the headers (names in blue) and the page. The server closes the connection when it is done: "Disconnected by peer".
Ctrl+S saves the whole exchange to a text file; Ctrl+H shows it as bytes.

Change the first line of the template to GET /robots.txt HTTP/1.1 before pressing Enter to ask for another page; Up brings the request back after it was sent.

Send a file from the BC-250 to a PC¶

No shared folder, no SSH set up: a Listen tab on the PC and a Connect tab on the board, or the other way round. Any netcat on the other side works too (nc -l 4444 > file on Linux).

On the receiving machine, Ctrl+L for a Listen tab, interface 0.0.0.0, port 4444, Listen. Open the port in the firewall when the machine has one (sudo firewall-cmd --add-port=4444/tcp on Bazzite). Then File → Save Received Data to File… and pick where the file should go; the status bar shows its name.
On the sending machine, Ctrl+T, the receiver's IP address, port 4444, Connect. The receiver's status bar shows "Connected (client …)".
File → Send File… (Ctrl+Shift+F) and pick the file. The status bar reports the byte count.
On the receiver, untick Save Received Data to File, then press Disconnect: the file is complete.

With a Listen tab on each side and a Connect tab on each side, the two machines also chat: type on one, read on the other, in both directions.

Watch a device that talks on the network¶

A printer, a sensor or a game console that sends status lines, or a service you want to see talking to a client.

To see what a device sends to a port: Ctrl+L, the port it sends to, UDP when it sends datagrams, Listen. Every line shows up as it arrives; Send answers the last sender. Switch on Reconnect Automatically for a Connect tab to a device that reboots: the tab reconnects by itself.
To sit between a client and a server and see both sides: a Listen tab on the port the client uses, a Connect tab to the real server, and a pipe each way (Session → Pipe Received Data To, on both tabs). Point the client at this machine. Each tab's log shows one direction; Hex View shows the bytes when the protocol is not text.
To repeat a login or a handshake later: do it once by hand, File → Save Session Recording, and Replay Recording on a fresh connection sends it again with the same pauses.

From the terminal¶

bazzite-netcatgui                      # the window with an empty Connect tab
bazzite-netcatgui example.org 80       # a Connect tab to example.org port 80, connected
bazzite-netcatgui -l 4444              # a Listen tab on port 4444, listening
bazzite-netcatgui -u -l 4444           # the same with UDP

The arguments follow nc: host port connects, -l port listens, -u makes that tab UDP. Everything else happens in the window. The window opens once: when it is already open, the command opens its tab there, beside the others.

Files¶

~/.config/bazzite-netcatgui/bazzite-netcatgui.ini: the Session menu's last state (the defaults for new tabs: newline, line ending, encoding, echo, reconnect, highlighting), the last twenty hosts and ports typed in Connect tabs and ports in Listen tabs (the drop-down lists), the folders of the last saved log, file and recording, and the window size.

Nothing else is written unless you save a log, a recording, or received data to a file.

When something does not work¶

"Connection refused": nothing listens on that host and port, or a firewall answered for it. With UDP the message comes after a send, when the port unreachable answer arrives; some hosts never send one.
"Hostname fail": the name could not be looked up. Try the IP address.
"Cannot start listen": the port is taken by another program, is below 1024, or the interface has no such address. Pick another port or 0.0.0.0.
Another machine cannot reach a Listen tab: the tab listens on 0.0.0.0 (or the machine's own address, not 127.0.0.1), and the port is open in the firewall (see What it needs).
Text comes out wrong: both sides must use the same encoding. Latin-1 shows every byte as a character and loses nothing; Hex View shows the bytes themselves.
"TLS handshake failed": the port does not speak TLS (plain TCP, or STARTTLS, which the app does not do), or you answered No to the certificate question.
A replay or a pipe sends nothing: the tab it sends through has no connection at that moment. The status bar shows the tab's state; connect first.
No window on an X11 session: PyQt6's X11 plugin needs libxcb-cursor; Bazzite's Wayland sessions do not. QT_QPA_PLATFORM=xcb bazzite-netcatgui or =wayland picks the backend by hand.

How it works¶

Each tab owns one Qt socket: a QTcpSocket or QSslSocket (Connect, TCP or TLS), a QTcpServer with the one accepted QTcpSocket (Listen, TCP), or a QUdpSocket (UDP, connected to the peer on a Connect tab, bound to the port on a Listen tab). The sockets run in the window's event loop, so nothing blocks and no threads are needed: data is read when it arrives and appended to the log, and what you send is written straight to the socket. The code is a port of NetcatGUI's C++ sources (src/netcatgui.cpp, src/widgets/ncsession*.cpp), with the same messages where it does the same thing.

License¶

GPL-2.0 (the app's LICENSE): the license of NetcatGUI by Shinnok (Teodor Mircea Ionita), which this app is a port of. The icons are from the Silk icon set 1.3 by Mark James, famfamfam.com (CC BY 2.5).
