BC-250 Cores Bisect

Tells bad CPU cores apart from an unstable core unlock on the AMD BC-250 (Cyan Skillfish), before you trust or persist the 8C/16T unlock.

The BC-250 ships with 6 of its 8 Zen 2 cores enabled (presence mask 0x77: core 3 of each CCX fused off, symmetric — which smells like product segmentation, not harvesting). The SMU exposes a quirk (queue-3 message 0x98) that writes 0xFF to any SMN address, including the core presence mask at SMN 0x5A870, which the host can't write. That enables all 8 cores on the next warm reboot.

The catch: that primitive is all-or-nothing. Unlike a GPU CU unlock there is no per-core mask, so you can't leave one bad core disabled. If either extra core is bad, the unlock is unusable on your board — and you want to know that before you persist it and let a flaky core corrupt data.

bc250-cores-bisect.sh does its own unlock, so no other tool is involved, and tests in a way that separates the possible causes. Sibling project of bc250-cu-bisect, which does the same for the GPU CUs.

Warning: this talks to the SMU and runs heavy CPU load. A bad core can freeze the system or corrupt data. Save your work first. Use at your own risk.

How it works

Since the cores can't be enabled one at a time, the isolation happens after the unlock, with the load pinned (taskset) to exactly the threads under test:

Item	When	Pinned to	Separates
control	before unlock	all stock cores (6C/12T)	board / power / heat / load tool problems
post-control	after unlock	one stock core (2 threads)	"the unlock destabilises the SoC" from bad cores
coreN	after unlock	one new core on its own	which new core (if any) is bad
combined	after unlock	both new cores together	cores that pass alone but fail together

          core0   core1   core2   core4   core5   core6   core3   core7
           ██      ██      ██      ██      ██      ██      ..      ..

██ stock, always enabled (6C/12T)    .. fused off, enabled by the unlock, tested one by one

The order isn't a typo: the map groups the stock cores first and the unlocked ones last, where their verdict cells live. Why cores 3 and 7 specifically? The mask 0x77 is binary 0111 0111 — one nibble per 4-core CCX, and in each CCX it's core 3 that is fused off. CCX0 keeps cores 0,1,2 and CCX1 keeps 4,5,6; the unlock adds core 3 (CCX0) and core 7 (CCX1's "core 3"). That symmetry — the same position disabled in both CCXs — is what smells like product segmentation rather than harvesting of defective silicon.

The script shows this map live, with >> on the core under test and ok/xx/?? once a core has a verdict (GOOD / FAILS EVERY TIME / RANDOM).

Failures are detected four ways:

• Machine-check events in the kernel log (journalctl -k) — the classic symptom of marginal cores.
• Wrong results, not only crashes: stress-ng --verify recomputes and checks every stressor result.
• Full crashes, crash-safe: before every attempt the script saves what it's doing. After a freeze, reboot and run it again: it records the crash and shows the MCE lines of the previous boot.
• Optional burn-in extras: mprime's torture test (--load mprime|both) and hardware error counters from rasdaemon (--rasdaemon); see Longer burn-in.

The test plan, same philosophy as the CU bisect:

• Control first: the unlock is only offered after the stock cores pass every control round. A failing control means nothing can be concluded about the new cores.
• Rounds: every item runs several times (default 3), interleaved, so heat and time don't favor one.
• One attempt per boot (default): warm reboots preserve the unlock, so isolation costs nothing.
• State machine across boots: control → unlock → verify the cores actually came up → bisect → verdict. A cold boot mid-run is detected (mask back to 0x77) and handled.
• Mask gate: boards whose stock mask isn't 0x77 are refused — a different mask strongly suggests genuinely defective silicon that was purposefully skipped.

The verdict and the decision

• control fails → board, power, heat or load tool. Fix that first.
• post-control fails → the unlock destabilises even the stock cores on your board. Cold boot to revert; don't persist.
• A core FAILS EVERY TIME → likely genuinely bad silicon. Because the unlock is all-or-nothing: don't use it at all. Cold boot (full power off) reverts everything.
• RANDOM failures → points to power or heat, not silicon. Improve cooling and retest.
• Everything GOOD, alone and combined → the unlock looks safe; persist it (below).

Requirements

• AMD BC-250, Linux with bash 4+. Tested against Bazzite (Fedora Atomic).
• setpci (pciutils) — SMN/SMU access goes through the PCI config space of 0000:00:00.0.
• stress-ng and taskset (util-linux).
• sudo rights (for setpci and the kernel log only).
• Optional: mprime (Prime95) for the torture test and rasdaemon (ras-mc-ctl) for hardware error counters. Both are only needed if you ask for them.

Before you start

1. Start from a cold boot (full power off) so the stock 0x77 state is guaranteed.
2. Close background workloads; the load must land only on the pinned cores.
3. The script stops cyan-skillfish-governor-smu for the few milliseconds of the SMU write (the governor shares the mailbox) and restarts it afterwards.

Usage

Run it as your normal user:

chmod +x bc250-cores-bisect.sh
./bc250-cores-bisect.sh                 # 3 rounds, 600 s verified load per attempt
./bc250-cores-bisect.sh -t 1800 -r 5    # longer load, more rounds (recommended before trusting it)
./bc250-cores-bisect.sh --same-boot     # no reboots between bisect attempts (faster, less isolation)
./bc250-cores-bisect.sh --auto          # no prompts, auto-reboot, continues after every login
./bc250-cores-bisect.sh --load both     # stress-ng *and* the mprime torture test per attempt
./bc250-cores-bisect.sh --rasdaemon     # also count hardware errors via ras-mc-ctl
./bc250-cores-bisect.sh --status        # results so far, report + logs in ~/Desktop/bc250-cores-bisect/
./bc250-cores-bisect.sh --reset         # delete the results and start over
./bc250-cores-bisect.sh --help

Note: -t minimum = 60

Flow: run → control rounds (one per boot) → it offers the unlock → warm reboot → it detects the new cores → bisect rounds (one per warm reboot) → final summary, report and decision.

At the end of a run (and on every --status) everything is copied to ~/Desktop/bc250-cores-bisect/ for easy sharing:

File	Contents
bc250-cores-bisect-results-<date>.txt	The report: core map, verdicts, decision, every attempt.
runs.tsv	The raw results table, one line per attempt.
config	The run's settings and detected cores.
logs/<date>-r<round>-<item>.log	stress-ng output of each attempt (verification failures etc).
logs/<date>-r<round>-<item>-mprime.log	mprime torture output, when mprime is part of the load.
ras-mc-ctl-errors.txt	rasdaemon's error table, when --rasdaemon is used.
auto.log	Everything the script printed in --auto runs.

The working copies live in ~/.local/share/bc250-cores-bisect/; --reset deletes those, not the Desktop folder.

Pick -t/-r before you start and keep them. You can change them mid-run (results so far are kept and the script asks you to confirm), but the evidence is then mixed: the report lists the load of every attempt, and a control that finished with fewer rounds keeps them. For a uniform result, use --reset and start over.

For --auto, install the autostart unit (see bc250-cores-bisect-auto.service.example) so the script resumes after every login.

Running truly unattended (--auto checklist)

--auto makes the script hands-off, but the system must get back to your session on its own:

1. Autologin — after each reboot someone must log in, or the run stalls at the login screen. Enable it in your desktop (Bazzite/KDE: System Settings → Colors & Themes → Login Screen (SDDM) → Behavior → auto-login, or Users → auto-login on GNOME).
2. Passwordless sudo for your user — the script needs setpci and journalctl -k without a prompt (there is no terminal to type a password into when it runs from the unit):

echo "$USER ALL=(ALL) NOPASSWD: ALL" | sudo tee /etc/sudoers.d/bc250-bisect
sudo chmod 440 /etc/sudoers.d/bc250-bisect
sudo visudo -cf /etc/sudoers.d/bc250-bisect   # must print "parsed OK"
sudo -k && sudo -n true && echo OK    # must print OK without asking

Revert after testing with sudo rm /etc/sudoers.d/bc250-bisect. If you edit the file by hand, use sudo visudo -f /etc/sudoers.d/bc250-bisect: it refuses to save a broken line. A broken line makes every sudo command print a warning, or stops sudo working at all. 3. The autostart unit installed — without it nothing restarts the script after login and you'd have to start it manually every boot. 4. No credential popups at login (KDE Wallet / ksshaskpass) — with autologin the KDE Wallet can't auto-unlock, so a "SSH credentials" / wallet dialog can appear at session start and block the chain until answered. Either give the wallet a blank password (open it in kwalletmanager5 first, then Change Password → empty), or disable the wallet subsystem (Plasma 6 has no UI checkbox for it anymore):

kwriteconfig6 --file kwalletrc --group Wallet --key Enabled false   # kwriteconfig5 on Plasma 5

Re-enable afterwards with ... --key Enabled true. Also uncheck "Use KWallet for the Secret Service interface" in System Settings → KDE Wallet so apps don't route secrets to the disabled wallet.

Check on it while it runs:

systemctl --user status bc250-cores-bisect-auto.service   # ran / running / failed this boot
tail -f ~/.local/share/bc250-cores-bisect/auto.log        # live output of the current attempt
./bc250-cores-bisect.sh --status                          # progress and results so far

When all attempts are done the script stops rebooting on its own; in --auto mode it also disables the autostart unit and removes the live-output entry (below) by itself, so nothing starts at the next login. If you ran without --auto, disable the unit manually (systemctl --user disable --now bc250-cores-bisect-auto.service).

Want the live output on the board's screen instead of a shell? Add a desktop autostart entry that opens a terminal following the log at every login (KDE example; see the comments in bc250-cores-bisect-auto.service.example):

cat > ~/.config/autostart/bc250-cores-bisect-watch.desktop <<'EOF'
[Desktop Entry]
Type=Application
Name=BC-250 bisect live output
Exec=konsole --title "bc250-cores-bisect" -e tail -n 40 -f .local/share/bc250-cores-bisect/auto.log
EOF

How long does it take?

A full run is 5 × rounds attempts (control, then post-control + core3 + core7 + combined), each running the load for --time seconds, plus one warm reboot for the unlock. In the default one-attempt-per-boot mode add a reboot-and-login (~1–2 min) per attempt; with --same-boot only 2–3 reboots total plus a 30 s cooldown between attempts. Indications:

Invocation	Attempts	Pure load	Wall clock (approx.)
default (-t 600 -r 3)	15	2 h 30 m	~3 h (15 reboots)
--same-boot (-t 600 -r 3)	15	2 h 30 m	~2 h 45 m (3 reboots)
-t 1800 -r 5 (recommended)	25	12 h 30 m	~13 h (25 reboots)
-t 1800 -r 5 --same-boot	25	12 h 30 m	~12 h 45 m (3 reboots)

The longer runs are meant to be unattended: combine them with --auto (and the autostart unit) and let it finish overnight. You don't have to do it in one sitting either — the state survives reboots, so run the script again at any time and it continues where it left off (--status shows progress).

Longer burn-in (mprime / rasdaemon)

stress-ng --verify is the default load and is enough for most boards. If you want a harder, longer burn-in before you trust the unlock, two optional tools can be folded in:

./bc250-cores-bisect.sh --load mprime              # mprime torture test instead of stress-ng
./bc250-cores-bisect.sh --load both                # stress-ng first, then mprime
./bc250-cores-bisect.sh --mprime-bin ~/mprime/mprime
./bc250-cores-bisect.sh --rasdaemon                # count hardware errors around every attempt
./bc250-cores-bisect.sh -t 1800 -r 5 --load both --rasdaemon --auto --same-boot

• --load stress-ng|mprime|both (default stress-ng). mprime runs Prime95's torture test (StressTester=1, no PrimeNet) pinned to exactly the same CPUs as stress-ng, from a private working directory under ~/.local/share/bc250-cores-bisect/mprime/<item>/. It is an AVX/FMA-heavy, in-cache FFT workload, which catches a different class of marginal silicon than stress-ng's mixed stressors. A torture error gives the attempt the outcome MPRIME-FAIL.
• With --load both the two tools run one after the other, never at the same time, so they don't fight over the same threads. Each attempt therefore takes 2 × --time — budget double the wall clock from the table above.
• --mprime-bin PATH points at an mprime binary that isn't on $PATH (the official builds from mersenne.org are a plain tarball, so this is the normal case).
• --rasdaemon reads ras-mc-ctl --errors before and after every attempt and records the difference. Any new hardware error makes the attempt RAS-ERROR. It needs a running rasdaemon service; if ras-mc-ctl is missing or unusable the script says so and carries on without it. The full error table is exported as ras-mc-ctl-errors.txt.
• Both extras are recorded per attempt: runs.tsv gained a load tool and a rasdaemon errors column, and the report lists the load of every attempt, so a mixed run stays readable. Older result files from before this feature are still read correctly.

Like -t/-r, pick these before you start: the settings are stored in config, reused after every reboot, and carried into the --auto service's command line.

Making it persistent

Only after a clean verdict:

sudo ./bc250-cores-unlock.sh --install

The unlock is volatile: it survives warm reboots, a full power off reverts it, and a fresh write only takes effect on the next reboot. So --install copies the script to /usr/local/sbin (root-owned) and enables a root service that checks the mask early at every boot; after a cold boot it re-applies the unlock and warm-reboots once (a guard file prevents reboot loops if the unlock ever stops taking effect). --uninstall removes the service and the copy; the stock 6C/12T returns after the next full power off. --status shows mask, threads, service and guard state.

A BIOS-mod route exists for true permanence (RescueMei/BC250-DXEv3-BIOSMOD) but is out of scope here: this project stays software-only and reversible.

GUI

Two separate PyQt6 front-ends ship with the project: a setup GUI that starts a bisect run, and an unlock GUI for the persistence step afterwards. Both are optional — everything they do can be typed by hand.

Recommended: install.sh (from a clone or the extracted release tarball). It installs both GUIs at once: a root-owned copy of the toolset in /opt/bc250-cores-bisect-v<version> (with /opt/bc250-cores-bisect pointing at it), a private PyQt6 venv in ~/.local/share/bc250-cores-bisect-app/venv, both launchers in ~/.local/bin, app menu entries and Desktop icons. Run it as your own user — only the copy to /opt asks for the sudo password.

./install.sh                         # install or update both GUIs
./install.sh --bisect-only           # or --unlock-only
./install.sh --no-desktop-shortcut   # app menu entries only
./install.sh --uninstall             # remove the apps; keeps results, settings and logs
./install.sh --uninstall --purge     # also remove results, settings, logs and the autostart unit

Your bisect results stay in ~/.local/share/bc250-cores-bisect; the installer never touches that folder unless you pass --purge. Installing also clears out any older per-user install made by the packaging/bazzite/ scripts below, so you don't end up with two menu entries per GUI.

Setup GUI (cores_bisect)

A one-screen "initial setup" for bc250-cores-bisect.sh: pick the load time, the rounds per item, the load tool and the two run-mode switches (--same-boot, --auto), then click Start Cores Bisect. The window closes and the real run continues in a terminal, exactly as if you had typed the command — the GUI only assembles the command line, so the script stays the single source of truth.

• An estimate of the total runtime updates as you change the options.
• Load tool picks between stress-ng, mprime and both; Also count hardware errors with rasdaemon adds --rasdaemon. See Longer burn-in.
• Unattended can also install and enable the auto-resume login service for you (~/.config/systemd/user/bc250-cores-bisect-auto.service), the same thing the --auto checklist describes. The script removes it again once every item is done.
• Show status (--status) and Reset (--reset) run in a terminal too, so the script can still ask for its own confirmation.
• Help shows the script's own --help, so it can never drift out of sync.

Per-user alternative, one GUI only (no /opt, nothing root-owned):

bash packaging/bazzite/install-bisect-gui.sh     # venv + launcher + menu entry "BC-250 Cores Bisect"
bash packaging/bazzite/uninstall-bisect-gui.sh   # removes all of that again (keeps your results)

Installed per user under ~/.local/share/bc250-cores-bisect-gui, launcher ~/.local/bin/bc250-cores-bisect-gui.

Unlock GUI (cores_unlock)

cores_unlock is a small PyQt6 front-end for the persistence step. It doesn't run the bisect — that stays a terminal job, because it reboots and runs for hours — but it reads the results that bc250-cores-bisect.sh left in ~/.local/share/bc250-cores-bisect and puts --install behind a verdict gate:

• ACCEPTED only when the bisect phase is finished, no attempt is still in progress, control and post-control are clean, and every new core and the combined item passed every round. Notes (e.g. control ran fewer rounds, or loads changed mid-run) are shown but don't block.
• NOT ACCEPTED YET otherwise, with the reason (unfinished, failing core, random failures, …). Install stays disabled; Uninstall, Refresh status, Status with sudo and Re-check always work.
• A core map shows the 6 stock cores and the 2 unlocked ones (ok / xx fails / ?? random / .. not tested).

Install/Uninstall run bc250-cores-unlock.sh via sudo; you're only asked for a password when sudo actually needs one. Refresh status runs unprivileged (the mask is shown if sudo needs no password); Status with sudo runs the same status as root, asking for the password if needed, so the mask is always shown.

Bazzite (or any desktop, no root or rpm-ostree needed): per-user alternative to install.sh, this GUI only:

bash packaging/bazzite/install-gui.sh     # venv + launcher + menu entry "BC-250 Cores Unlock"
bash packaging/bazzite/uninstall-gui.sh   # removes all of that again (not the unlock service)

It installs per user under ~/.local/share/bc250-cores-unlock-gui, with the launcher ~/.local/bin/bc250-cores-unlock-gui. The names don't clash with each other or with the bc250-cu-bisect GUIs, so they can all be installed side by side.

From a venv (development):

python3 -m venv .venv && .venv/bin/pip install -r requirements.txt
.venv/bin/python -m cores_bisect  # --script PATH to use another bc250-cores-bisect.sh
.venv/bin/python -m cores_unlock         # --script PATH to use another bc250-cores-unlock.sh

Known side effect

After the unlock, pp_dpm_sclk and hwmon freq1_input report nonsense GPU clocks (tens of MHz). This is cosmetic — the SMU's own clock getters stay correct — and this script ignores GPU clocks. Diagnostics that read those files (e.g. tests 19/40 of Bazzite Test) will flag it; that's expected while the unlock is active.

Credits

The SMU quirk (queue-3 message 0x98 → 0xFF at SMN 0x5A870) was discovered and documented by rw-r-r-0644/bc250-core-unlock (MIT). This project is an independent implementation built around those hardware facts, adding the control/bisect/verdict methodology, crash-safe multi-boot state, and reversible persistence.

License

GNU GPLv3, see LICENSE.
